2022 Equinox in AUSTIN

Highway

1.5L turbo DOHC DI with automatic stop/start

Bore & Stroke
(in / mm):

2.9 x 3.4 / 74 x 86.6

Block Material:

Cast aluminum

Cylinder Head Material:

Cast aluminum

Valvetrain:

Dual overhead camshafts; four valves per cylinder

Fuel Delivery:

Direct injection

Horsepower
(hp / kW @ rpm):

170 / 127 @ 5600 (SAE-certified)

Torque
(lb.-ft./ Nm @ rpm):

203 / 275 @ 2000-4000 (SAE-certified)

Hydra-Matic 6T40 six-speed automatic

Gear Ratios (:1)

6T40

     First

4.58

     Second

2.96

     Third

1.91

     Fourth

1.44

     Fifth

1.00

     Sixth

0.74

     Reverse

2.94

Final Drive Ratio:

3.50 (FWD)
3.87 (AWD)

MacPherson strut with specifically tuned coil springs, direct-acting stabilizer bar

Rear Suspension:

Four-link independent rear suspension

Steering Type:

Electric power-assisted rack-and-pinion

Turning Circle
(ft. / m):

37.4 / 11.4 (17-in. wheels)
38.4 / 11.7 (18-in. wheels)
41.6 / 12.7 (19-in. wheels)

Brake Type:

Four-wheel disc with ABS and ESC; Duralife rotors with low-drag calipers

Brake Rotor Size
(in / mm):

Front: 11.8 / 300
Rear: 11.3 / 288

Wheel Size:

17-in. aluminum (std. LS and LT)
18-in. aluminum (std. Premier, avail. LT)
19-in. aluminum (std. RS, avail. LT and Premier)

Tire Size:

P225/65R17
P225/60R18
P235/50R19

107.3 / 2725

Overall Length
(in. / mm):

183.1 / 4652

Overall Width
(in. / mm):

72.6 / 1843

Overall Height
(in. / mm):

65.4 / 1661

Track (in. mm):

Front: 62.2 / 1580
Rear: 62.2 / 1581

Ground clearance   (in. / mm):

7.6 / 193 (FWD w/ 17-in. wheels)
7.9 / 202 (AWD w /17-in. wheels)
8.0 / 204 (AWD w/ 18-in. wheels)
TBD (FWD w/ 19-in. wheels)

40.0 / 1016 (front w/o sunroof)
38.2 / 970 (front w/ sunroof)
38.5 / 977 (rear w/o sunroof)
36.9 / 936 (rear w/ sunroof)

Legroom (in. / mm):

40.9 / 1040 (front)
39.9 / 1013 (rear)

Shoulder Room       (in. / mm):

57.2 / 1453 (front)
55.5 / 1410 (rear)

Hip Room (in. / mm):

54.2 / 1377 (front)
51.7 / 1313 (rear)

3274 / 1485 – LS FWD
3465 / 1572 – LS AWD
3325 / 1508 – LT & RS FWD
3478 / 1578 – LT & RS AWD
3350 / 1520 – Premier FWD
3512 / 1593 – Premier AWD

EPA Passenger Volume (cu. ft. / L):

103.5 / 2931

Max Cargo Volume (cu. ft. / L)1:

63.9 / 1809 (rear seat folded)
29.9 / 846 (behind rear seat)

Trailering Capacity
(lb. / kg)2:

1500 / 680

Standard Tire Pressure Monitor System; tire pressure monitor includes tire fill alert (excludes spare tire, if equipped)

Standard Rear Vision Camera² (HD view on Premier)

Standard Chevy Safety Assist². Content includes Automatic Emergency Braking, Following Distance Indicator, Forward Collision Alert, Front Pedestrian Braking, Lane Keep Assist with Lane Departure Warning and IntelliBeam, automatic high beams

Driver Confidence II Package² is standard on RS and Premier and available on LS and LT. Content includes Rear Cross Traffic Alert and Lane Change Alert with Side Blind Zone Alert

Advanced Safety Package² is available on LT and RS. Content includes HD Surround Vision, Adaptive Cruise Control and outside heated power-adjustable manual-folding mirrors with integrated turn signal indicators

Driver Confidence III Package² is available on Premier. Content includes Automatic Parking Assist, HD Surround Vision and Adaptive Cruise Control

Safety Alert Seat is standard on Premier
